Online Catalog

LPD Series

Low Pressure Drop Type

Fin Dimensions

Thickness : 0.75 - 0.95 mm
Gap : 3.10 - 3.91 mm

Heat Sink Height

3.0 - 40.0 mm

MD Series

Middle Density Type

Fin Dimensions

Thickness : 0.75 - 0.95 mm
Gap : 2.28 - 2.98 mm

Heat Sink Height

6.0 - 30.0 mm

W Series

Stanadrd elliptical fin.

Fin Dimensions

Thickness : 0.80 - 1.80 mm
Gap : 1.80 - 2.34 mm

Heat Sink Height

10.0 - 45.0 mm

L Series

High Profile Type

Fin Dimensions

Thickness : 1.10 mm
Gap : 2.34 mm

Heat Sink Height

30.0 - 60.0 mm

LC Series

Copper Embedded L Type Heat Sink

LT Series

Line Type fin.

Fin Dimensions

Thickness : 0.70 - 0.90 mm
Gap : 1.86 - 2.29 mm

Heat Sink Height

20.0 - 45.0 mm

UB Series

0.55mm Elliptical Fins.

Fin Dimensions

Thickness : 0.50 - 0.55 mm
Gap : 1.45-1.64 mm

Heat Sink Height

5.0 - 30.0 mm

UBC Series

Copper Embedded UB Type Heat Sink

Z Series

0.35mm fin thickness.

Fin Dimensions

Thickness : 0.35 mm
Gap : 1.13 - 1.17 mm

Heat Sink Height

6.3 - 12.7 mm

T Series

0.23mm fin thickness.
For small package.

Fin Dimensions

Thickness : 0.23 mm
Gap : 1.02 - 1.04 mm

Heat Sink Height

3.0 - 6.0 mm

N Series

Omnidirectional hexagon pin fin heat sinks. Sparse fin pattern. Suitable for natural convection.

Pin Dimensions

Thickness : 1.90 - 2.50 mm
Gap : 5.78 - 7.87 mm

Heat Sink Height

10.0 - 40.0 mm

CS Series

High Aspect Ratio
Omnidirectional square pin fin heat sinks.

Pin Dimensions

Thickness : 1.45 mm
Gap : 2.31 - 2.59 mm

Heat Sink Height

50.0 mm

S Series

Omnidirectional square pin fin heat sinks.

Pin Dimensions

Thickness : 1.45 - 2.00 mm
Gap : 1.98 - 2.40 mm

Heat Sink Height

5.0 - 40.0 mm

ST Series

Omnidirectional heat sinks featuring thin, low profile, pins. Suitable for applications with very limited space.

Pin Dimensions

Thickness : 0.75 - 0.80 mm
Gap : 1.20 - 1.40 mm

Heat Sink Height

4.0 - 7.0 mm
